AMAT 0010-06825 Wafer Alignment Sensor Assembly

Product Overview: The AMAT 0010-06825 is a high-precision wafer alignment sensor assembly designed for Applied Materials semiconductor equipment. It provides real-time, non-contact wafer alignment and notch detection, ensuring precise wafer positioning within process chambers and wafer handling systems. This assembly features advanced optical sensing technology, high-speed data processing, and seamless integration with AMAT’s control systems.

Technical Specifications:

  • Sensing Technology: Laser-based optical alignment, with a 650nm red laser source.
  • Alignment Accuracy: ±0.005mm for wafer centering, ±0.01° for notch detection.

Detailed content

  • Response Time: ≤10ms for alignment measurement and data output.
  • Wafer Compatibility: 200mm and 300mm wafers, with standard notch or flat orientations.
  • Operating Environment: Cleanroom Class 1, temperature 18–25°C, humidity 40–60% (non-condensing).
  • Output: Digital RS-485 and analog 0–10V signals for equipment control integration.
  • Dimensions: 100mm×80mm×60mm, weight 0.8kg.
  • Certification: Complies with SEMI S2/S8 safety standards and ISO 14644-1 cleanroom requirements.

    Functional Features:

  • Provides non-contact, high-precision wafer alignment and notch detection.
  • Delivers fast response times for real-time process control.
  • Resists contamination, with a sealed, cleanroom-compatible design.
  • Seamless integration with AMAT’s wafer handling and process control systems.
  • Minimizes particle generation, with smooth, anti-static surfaces.
  • Easy to calibrate and maintain, ensuring long-term reliability.

    Application Scenarios:

  • Installed in AMAT process chambers and wafer handling systems for wafer alignment.
  • Used in 200mm and 300mm wafer fabs for logic, memory, and power semiconductor manufacturing.
  • Applied in processes requiring precise wafer positioning (≤5nm nodes).
  • Ideal for high-volume production lines requiring consistent wafer alignment.
  • Deployed in R&D facilities for wafer process development and alignment optimization.
