Model Type:SLC500

Model Number:1746-NIO4V/A

Manufacturer:Allen Bradley

Module Type:Analog Combination Module

Resolution:High Resolution

Input Channels:2

Output Channels:2

Input Voltage Range:-20 to 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Maximum)

Input Current Range:-20 to 20 mA

Absolute Input Current:-30 to 30 mA (Maximum)

Output Range:-10 to 10 V – 1 LSB

Full Scale Output:10 VDC

Overvoltage Protection:7.5 VAC RMS

Output Voltage Range:-10 to 10 VDC – 1 LSB

Backplane Current Draw:55 mA

    The Allen Bradley SLC500 1746-NIO4V is a high-performance analog combination module ideal for industrial control systems.

     Its design includes two input channels and two output channels, making it a versatile solution for various applications.

     With a wide input voltage range of -20 to 20 V and an input current range of -20 to 20 mA, this module ensures precise and reliable data acquisition.

     The output range of -10 to 10 V provides accurate control signals, while overvoltage protection ensures long-term reliability.

     Additionally, the backplane current draw of 55 mA makes it energy-efficient and easy to integrate into existing systems.

     Whether you’re working on manufacturing processes, automation systems, or any other industrial application, the Allen Bradley SLC500 1746-NIO4V delivers the precision and performance needed to meet your needs.
