Allen Bradley AB 1756-EN2TR ControlLogix EtherNet/IP Module
The Allen-Bradley AB 1756-EN2TR/B ControlLogix EtherNet/IP Module is a high-performance communication module designed for seamless integration into advanced industrial control systems, enabling efficient data exchange and enhanced connectivity.
Detailed content
Model Type:High Capacity IP Module
Manufacturer:Allen-Bradley
Communication Protocol:EtherNet/IP Bridge
Communication Speed:10/100 Mbps
Enclosure Type:Open Type
Connection Cables:802.3 compliant shielded or unshielded twisted pair
Temperature Rating:0 – 60°C
Power Dissipation:5.1 W
Isolation:30 V continuous
Environmental Conditions:5 – 95% non-condensing relative humidity
Vibration Resistance:2 G
Shock Resistance:30 G
Interface:Ethernet
USB Port:Provided for software updates and data transfer
Engineered for optimal performance in demanding industrial environments, the Allen Bradley AB 1756-EN2TR module ensures reliable data transmission through its robust EtherNet/IP interface, enhancing efficiency in control systems.
With support for up to 2 Ethernet ports and 8 motion axes, this module facilitates complex automation tasks, making it suitable for applications requiring precise coordination and control.
Featuring a compact design that seamlessly integrates into existing ControlLogix systems, the 1756EN2TR provides an easy upgrade path for expanding network capabilities without compromising on system integrity.
The open type enclosure ensures durability and protection against harsh industrial conditions, while the 5-pin Phoenix connector offers secure deviceNet integration for additional functionality.
Equipped with advanced isolation and environmental resistance features, this module ensures stable operation even in challenging industrial settings, guaranteeing uptime and minimizing downtime.
