Product Type:Adapter Module

Communication Protocol:ControlNet

Media Type:Dual

Supply Voltage:24V DC

Input Voltage Range:19.2 to 31.2 VDC

Isolation Voltage:850 VDC

Mounting Options:[“DIN Rail”,”Panel”]

Temperature Rating:-20 to 70 DEG C

Power Consumption:7.6 W at 19.2 VDC

Enclosure Type:Open

Environmental Conditions:5 – 95% non-condensing relative humidity

Shock Resistance:30 G operating

Vibration Resistance:5 G at 10 – 500 HZ

Compliance Standards:UL listed

    The Allen-Bradley AB 1794-ACN15/C Adapter Module is engineered for high-performance operation in industrial environments, offering robust compatibility with ControlNet networks. This module ensures efficient data transfer rates of up to 500 Kbps, facilitating smooth communication between PLCs and other network devices.

    Designed with an open-style enclosure, the AB 1794-ACN15/C is suitable for DIN rail or panel mounting, providing flexibility in installation options. It supports dual media connections, enhancing system reliability by allowing redundancy in case of single media failure.

    Featuring a 24V DC power supply, this adapter module is optimized for use in systems requiring precise voltage control, ensuring stable operation under various environmental conditions. Its isolation voltage rating ensures safety and protection against electrical surges, safeguarding connected devices from damage.

    Equipped with advanced isolation techniques, the AB 1794-ACN15/C Adapter Module offers superior noise immunity and signal integrity, crucial for maintaining accurate data transmission in noisy industrial settings. This feature is particularly beneficial in environments with high electromagnetic interference.

    With its comprehensive compatibility with Allen-Bradley‘s ControlLogix PLC series and ControlNet protocol, the AB 1794-ACN15/C Adapter Module simplifies the integration of new and existing automation systems, promoting efficient and scalable automation solutions for manufacturing and process industries.
