Allen-Bradley 1771-OD16 Digital Output Module
The A-B 1771-OD16 Digital Discrete Output Module is designed for industrial automation applications, providing reliable digital output control in various control systems. It is ideal for manufacturing environments where precise control over devices such as relays, actuators, and other industrial components is essential.
Detailed content
Brand:A-B
Model:1771-OD16
Module Type:Discrete Output Module
Number of Outputs:16
Operating Voltage Range:10-60VDC
Nominal Output Voltage:48VDC
Minimum Load Current:2.5mA
Certifications:CE, UL, RoHS
The A-B 1771-OD16 is a robust and versatile discrete output module that integrates seamlessly into Allen-Bradley PLC systems. With its 16-channel design, it ensures reliable signal transmission for various industrial control applications.
This module supports an operating voltage range from 10 to 60VDC, providing flexibility for different power supply configurations. The nominal output voltage of 48VDC ensures stable and consistent performance across a wide range of loads.
The minimum load current requirement of 2.5mA ensures efficient operation, minimizing energy waste while maintaining signal integrity. The module is certified by UL and CE, ensuring compliance with international safety standards.
Designed for durability, the A-B 1771-OD16 features rugged construction suitable for harsh industrial environments. Its compact size allows for easy integration into existing control panels without compromising space.
Installation is straightforward with clear labeling and intuitive connections. Regular maintenance and diagnostics can be easily performed using Allen-Bradley software tools, ensuring optimal system performance over time.
