Brand:Allen-Bradley

Model:1761-L32AWA

Module Type:MicroLogix Controller

Input Channels:12 Fast 24 VDC, 8 Normal 24 VDC

Output Channels:6 Relay, 3 Fast DC, 3 Normal DC

Power Supply:24 VDC

Mounting:DIN Rail, Panel

Communication Interfaces:(1) RS-232/RS-485, (1) Ethernet/IP

Dimensions:Length: 180 MM, Width: 90 MM, Height: 87 MM

Temperature Rating:-20 To 60 DEG C

Environmental Conditions:Relative Humidity: 5 – 95% Noncondensing, Vibration: 3 G At 10 – 500 HZ, Shock Operating: 30 G, Shock Non-operating: Panel Mount 50 GDIN Mount 40 G

    The Allen-Bradley 1761-L32AWA MicroLogix controller is a versatile and reliable solution for small-scale automation projects. It combines a robust design with advanced features to ensure seamless operation across various industrial settings.

    This controller comes equipped with 12 fast 24 VDC input channels and 8 normal 24 VDC input channels, providing extensive connectivity options. Additionally, it has 6 relay output channels, 3 fast DC output channels, and 3 normal DC output channels, catering to diverse application requirements.

    With a compact form factor of 180 MM in length, 90 MM in width, and 87 MM in height, the 1761-L32AWA controller can easily fit into tight spaces without compromising on functionality. It supports mounting options such as DIN rail or panel mounting.

    Equipped with communication interfaces like RS-232/RS-485 and Ethernet/IP, this controller ensures efficient data transfer and network integration. Its wide temperature range from -20°C to 60°C makes it suitable for harsh environmental conditions.

    Designed to withstand vibrations up to 3 G at frequencies between 10 Hz to 500 Hz and shocks up to 30 G during operation, the 1761-L32AWA controller is built to last in demanding industrial environments.
