Model Type:Analog Input

Manufacturer:Allen Bradley

Number of Channels:4

Common Mode Voltage Range:-20 To 20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max.)

Input Range:-20 To 20 MA

Absolute Input Current:-30 To 30 MA (Max.)

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Range (VDC):-10 To 10 VDC – 1 LSB

Current Rating (Backplane):35 MA at 5 V, 85 MA at 24 V

Isolation:Backplane: 500 VDC, Enclosure: Open Type

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95%

Form Factor:Chassis

Mounting:Panel

Power Consumption:1.8 W

Power Dissipation:6.1 BTU/HR

Standard/Approvals:GOST_R, KCC, MARINE-ABS, MARINE-BVS, MARINE-DNV, MARINE-GL, MARINE-KRS, MARINE-LR

    The 1746sc-INI4vi Analog Input Module is specifically engineered for seamless integration into SLC 500 systems, enhancing their performance with high-precision analog input capabilities.

    It offers 4 independent channels capable of handling a wide range of input signals from 0-10 VDC and 4-20 mA, ensuring accurate data acquisition for critical industrial processes.

    With an impressive accuracy of ±0.05% of full scale, this module guarantees reliable and precise measurements, crucial for maintaining operational efficiency in demanding environments.

    Equipped with an RS-485 communication interface, it supports various communication rates, allowing for flexible connectivity options and seamless data transfer within industrial networks.

    Operating within a temperature range of -20°C to +60°C and a humidity range of 5% to 95% non-condensing, this module is designed to withstand harsh industrial conditions, ensuring robust performance under extreme environmental challenges.
