Technical Specifications

• Type: Time Interval Analyzer
• Function: The E1740A is designed for precise measurement of time intervals, which makes it ideal for applications requiring high-resolution time or frequency analysis.
• Frequency Range: Typically supports a wide frequency range, allowing for versatile measurement capabilities. The specific range is detailed in the product documentation.
• Resolution: Offers high resolution, often in the picosecond range, ensuring very accurate time interval measurements.
• Channels: Typically includes multiple input channels, enabling simultaneous measurement of different signals. The exact number of channels is specified in the datasheet.
• Interface: Provides standard communication interfaces for connecting to external systems, such as GPIB (General Purpose Interface Bus) or RS-232, allowing for remote operation and data acquisition.

Features

• High Precision: The E1740A is designed to deliver highly precise time interval measurements, essential for applications where timing accuracy is critical.
• Multiple Measurement Functions: Supports various measurement functions, including time interval, frequency, period, and pulse width, making it versatile for different applications.
• Data Storage and Processing: Capable of storing and processing measurement data, which can be retrieved and analyzed later.
• Integration: Compatible with other Agilent/Keysight measurement systems, allowing it to be integrated into larger testing setups.
• User Interface: Typically features an intuitive user interface, with options for manual control and programming.

Application Scenarios

• Time and Frequency Calibration: Used in calibration labs for precise measurement and calibration of time and frequency standards.
• Telecommunications: Applied in the telecommunications industry for testing and verifying the timing and synchronization of communication signals.
• Research and Development: Utilized in R&D environments where accurate timing measurements are necessary, such as in the development of high-speed electronics.
• Metrology: Employed in metrology for the precise measurement of time intervals, which is crucial in various scientific and industrial applications.
