Model Series: BKF Series (Built-In Coffee)

Type: Fully Automatic Bean-to-Cup

Pump Pressure: 15 bar (Italian pump)

Bean Hopper Capacity: 275 g

Water Tank Capacity: 1.8 L (removable)

Coffee Bean Container: Integrated ceramic grinder with 5 grind settings

Milk System: AEG LatteGo system (integrated automatic milk frother with detachable milk carafe)

Beverage Options:

• Espresso
• Double Espresso
• Coffee (Americano style)
• Cappuccino
• Latte Macchiato
• Hot Water
• Ristretto

Display: Full-color TFT touchscreen (3.5 inch)

Dimensions (W x H x D): 596 mm x 380 mm x 550 mm (with door)

Cut-out Dimensions for Installation: 560 mm x 360 mm x 550 mm (minimum)

Power Supply: 220-240V / 50-60Hz / 1-phase

Rated Power: 1,450 W

Weight: 28 kg (net)

Structure Features:

• Fully flush-mounted installation into kitchen cabinetry
• Stainless steel front panel with soft-close door
• Ceramic burr grinder (adjustable: fine to coarse)
• Automatic descaling program
• Automatic rinsing cycle on startup/shutdown
• Adjustable spout height (65–135 mm)
• Adjustable coffee outlet (105–165 mm)

Material Composition:

• Housing: Stainless steel + ABS plastic
• Grinder: Ceramic burrs
• Drip tray: Stainless steel grid

Installation Requirements:

• Hardwired connection via dedicated 16A circuit with RCD protection
• Water connection: Ø 12 mm cold water inlet, pressure 1–10 bar
• Drain connection: Ø 16 mm drain hose
• Cabinet depth minimum 550 mm

Usage Notes:

• Use only AEG-branded descaler (model AEG MCD100)
• Empty drip tray daily to prevent overflow
• Clean milk carafe after every use
• Run descaling cycle every 2 months or after 200 cups
