Technical Specifications:

• Motor Type: AC Induction Motor (Shaded Pole / Permanent Split Capacitor)
• Rated Voltage: 220–240V AC, 50Hz
• Rated Power: 20W to 25W
• Rotational Speed: 2800 RPM (Nominal)
• Flow Rate: 8 to 12 Liters per Minute (Dependent on Pump Housing)
• Maximum Head Pressure: 0.8 to 1.2 Bar
• Noise Level: < 52 dB(A)
• Insulation Class: Class B (130°C)
• IP Rating: IPX4 (Splash-Proof)
• Dimensions: Approximately 100 mm x 85 mm x 75 mm (L x W x H)
• Weight: ~0.85 kg

Functions:

• Wash Water Circulation (Lower & Upper Spray Arms)
• Drain Pump Operation (Empty Tub After Cycle)
• Anti-Flood Protection (Continuous Drain During Fault)

Material Composition:

• Housing: Polypropylene (PP) — Glass Fiber Reinforced (30% GF)
• Impeller: PP + 30% GF (Injection Molded)
• Motor Windings: Copper Wire (Class B Enamel, 155°C Rating)
• Shaft Seal: Carbon/Ceramic Mechanical Seal
• Bearings: Sleeve Bearing (Sintered Bronze)

Structural Features:

• Inlet/Outlet Diameter: 22 mm (Hose Barb Connection)
• Electrical Connection: 2-Pin Faston Connector (6.3mm)
• Mounting: 3-Point Rubber Vibration Isolator

Applicable Models: AEG Dishwashers (F Series, S Series), AEG Washing Machines (L Series)

Installation Requirements:

• Mount using 3x M4 screws with rubber grommets
• Ensure inlet hose is secured with hose clamp (min. 16mm band width)
• Verify impeller rotates freely before connecting electrical supply

Usage Precautions:

• Do not run motor dry (will cause seal damage within 30 seconds)
• Clean impeller housing quarterly to prevent blockage
• Replace carbon brushes (if applicable) every 2000 operating hours
