AEG AS-B809-016
Product Overview:
The AEG AS-B809-016 is a built-in column refrigerator from the AEG 5000 Series, engineered for integrated kitchen installations. It features No Frost technology and electronic controls for precise temperature management.
Technical Specifications:
- Total Net Capacity: 122 Liters
Detailed content
- Climate Class: SN-T
- Energy Efficiency Class: A+
- Noise Level: 38 dB(A) re 1 pW
- Voltage/Frequency: 220-240V / 50Hz
- Current Rating: 1.0A
- Power Consumption: 112 kWh/year
- Dimensions (H×W×D): 880mm × 540mm × 547mm
- Weight (Net): 32 kg
- Installation Type: Built-in (Flush-mounted)
Functional Features:
- No Frost Technology: Complete elimination of frost accumulation.
- Electronic Temperature Controller: Digital display with precise adjustment.
- Automatic Defrost System: Freezer compartment defrosts automatically.
- Reversible Door: Left or right opening configurable.
- LED Interior Light: Built-in LED illumination.
- 3 Adjustable Tempered Glass Shelves: With chrome-finished edges.
- 3 Door Bins: Transparent front covers for visibility.
Material Composition:
- Interior: ABS Plastic (white, food-safe)
- Exterior: Powder-coated steel (white)
- Shelves: Tempered glass with stainless steel trim
- Seal: Magnetic PVC gasket
- Refrigerant: R600a (Isobutane)
Structural Features:
- Flush-mount capable with flat rear panel.
- Adjustable leveling feet (front).
- Minimum ventilation: 10mm top, 50mm rear.
Working Principle:
Hermetic compressor circulates R600a refrigerant through a closed-loop system. Fan-forced air distribution across the aluminum evaporator prevents frost formation (No Frost). Electronic control board reads NTC temperature sensor and modulates compressor duty cycle for stable interior temperature.
Key Advantages:
- No Frost — zero maintenance defrosting
- A+ rated for low energy consumption
- 38 dB(A) silent operation
- Fully reversible door hinge
- Eco-friendly R600a refrigerant (GWP=3)
Applicable Industries/Use Cases:
Residential kitchen integration, compact apartments, serviced apartments, commercial break rooms.
Installation Requirements:
- Dedicated circuit: 13A fused spur with earth.
- Cabinet cutout: 880 × 560 × 550 mm (H×W×D).
- Ventilation gap: 10mm top, 50mm rear.
- Professional installation mandatory.
Usage Precautions:
- Do not obstruct top or rear ventilation grilles.
- Wait 24 hours after positioning before switching on.
- Clean with non-abrasive cleaning agents only.
- Ensure door seal is intact to prevent energy loss.
