Model Series: ALU Series (AEG Laundry)

Type: Front-Loading Washing Machine

Load Capacity: 8 kg (cotton program)

Maximum Spin Speed: 1300 RPM

Energy Efficiency Class: A+++ (EU Energy Label 2021)

Annual Energy Consumption: 150 kWh/year (based on 220 standard cycles)

Water Consumption per Cycle: 49 liters (standard 60°C cotton cycle)

Noise Level (Washing): 51 dB(A)

Noise Level (Spinning): 76 dB(A)

Dimensions (W x H x D): 596 mm x 847 mm x 636 mm

Net Weight: 72 kg

Power Supply: 220-240V / 50Hz / 1-phase

Rated Power: 2,200 W (max, during heating)

Program Count: 14 preset programs + 3 custom programs

Program Options:

• Cotton 60°C
• Cotton 40°C
• Synthetics
• Delicates / Silk
• Wool / Hand Wash
• Rapid 20′
• Mixed Load
• Dark Wash
• Drum Clean
• Rinse + Spin
• Eco 40-60
• Outdoor
• Anti-Allergy
• Steam Refresh

Key Technologies:

• ÖKOMix: Pre-mixes detergent with water before contacting clothes for even distribution
• ProSteam: Steam injection at end of cycle to reduce wrinkles by up to 50%
• ProSense: Automatic load weight sensing to adjust water and energy usage
• SoftWater System: Built-in water softener to protect fabrics and machine
• TimeManager: Adjustable cycle time (20%–100% of standard duration)

Structure Features:

• Front-loading door with Ø 340 mm opening
• Stainless steel drum (480 mm diameter)
• Anti-vibration side panels for reduced noise
• LCD display with remaining time indicator
• Child lock function
• Foam detection system
• Unbalance control system

Material Composition:

• Drum: Stainless steel
• Door: Tempered glass + ABS frame
• Counterweight: Concrete (vibration dampening)
• Outer casing: Galvanized steel with powder coating

Installation Requirements:

• Level floor with 10 cm clearance behind for hose connections
• Water supply: Ø 15 mm cold water, pressure 0.5–10 bar
• Drain: Ø 22 mm standpipe or Ø 40 mm hose drain
• Dedicated 10A circuit with earth connection
• Transport bolts must be removed before first use (4 bolts at rear)
