Technical Specifications:

• Part Number: 92-00915-01
• Compatible Models: AEG AS-S985-022, AS-S908-110, and all S9000 Series indoor units
• Filter Type: Activated Carbon + Synthetic Fiber Composite
• Filtration Efficiency (PM2.5): >95%
• Odor Absorption Capacity: High — activated carbon density 200 g/m²
• Dimensions (W x H x D): 890 mm x 295 mm x 20 mm
• Weight: 0.12 kg
• Service Life: 6–12 months (depending on usage and air quality)
• Color: Dark Gray / Black

Material Composition:

• Primary Layer: Activated carbon granules (coconut shell origin) bonded to synthetic fiber matrix
• Frame: Rigid polypropylene (PP) frame with snap-fit mounting tabs
• Secondary Layer: Electrostatic synthetic fiber pre-filter mesh
• Adhesive: Heat-activated bonding agent (no harmful off-gassing)

Structural Features:

• Mounting Type: Snap-fit into dedicated filter slot behind the front panel
• Replacement Access: Front panel lifts upward for filter access — no tools required
• Orientation: Directional — airflow arrow printed on filter frame (must face correct direction)

Working Principle:
Air drawn into the indoor unit passes first through the washable synthetic pre-filter (capturing dust, hair, and large particles), then through the active carbon filter. Activated carbon removes gaseous pollutants and odors through adsorption — contaminant molecules adhere to the vast internal surface area of the carbon granules (typically 800–1,200 m²/g surface area). The electrostatic synthetic layer captures fine particulates down to 2.5 micrometers.

Advantages & Highlights:

• Genuine AEG Part: Exact fit for S9000 Series units — no aftermarket compatibility issues.
• Dual-Action Filtration: Combines particulate capture with gas/odor absorption in a single filter.
• Easy Replacement: Tool-free snap-in design — replacement takes under 30 seconds.
• Health Protection: Removes formaldehyde, benzene, and common household VOCs.

Applicable Industries / Use Cases:

• Residential air conditioning maintenance
• Commercial office HVAC filter replacement
• Any facility using AEG S9000 Series indoor units

Installation Requirements:

• Replacement Interval: Every 6 months minimum; every 3 months in high-pollution or high-cooking-odor environments.
• Direction: Ensure the airflow arrow on the filter aligns with the airflow direction indicated inside the unit.
• Do Not Wash: This is a disposable filter — do not attempt to clean or reuse.

Usage Precautions:

• Always use genuine AEG part number 92-00915-01 — aftermarket filters do not guarantee fit or performance.
• Do not install a dirty or damaged filter — it restricts airflow and reduces efficiency.
• Store spare filters in a dry, sealed bag away from direct sunlight.
• Replace immediately if the filter shows signs of saturation (strong odor when removed).
