• Accuracy: ±0.1% of full scale, ensuring precise measurement across all signal ranges.
• Conversion Time: 250 µs per channel, enabling real-time monitoring of dynamic processes.
• Isolation: 2500 V RMS between input and output circuits, protecting against electrical noise and ground faults.
• Power Consumption: 2.5 W under normal operation, optimized for energy efficiency.
• Environmental Ratings: IP20-rated enclosure for protection against solid objects ≥12mm, suitable for indoor control panels.
• Operating Temperature: -25°C to +70°C, maintaining stability in harsh industrial environments.
• Physical Design: Compact DIN rail-mountable form factor (73.66mm x 360.68mm x 269.24mm), weighing 0.771 kg for space-efficient installations.

Functional Features

• Multi-Signal Compatibility: Supports simultaneous input from TCs, RTDs, voltage, and current sources, eliminating the need for multiple modules.
• High-Speed Processing: Fast conversion rates allow seamless integration with high-frequency industrial processes.
• Diagnostic Capabilities: Built-in self-diagnostic functions monitor channel health, with LED indicators for real-time status feedback.
• Galvanic Isolation: Ensures signal integrity and protects downstream systems from voltage spikes.
• Flexible Configuration: Configurable via software tools (e.g., ABB’s System 800xA) to adapt to specific application requirements, including signal scaling and filtering.
• Communication Interfaces: Integrates with Modbus RTU and RS-485 for remote parameter adjustment and data transmission.

Application Scenarios

• Process Control: Monitors critical parameters like temperature, pressure, and flow in chemical plants, oil refineries, and water treatment facilities.
• Power Generation: Used in power plant auxiliary systems to monitor turbine temperatures, boiler feedwater pressure, and generator performance.
• HVAC Systems: Manages environmental controls in commercial buildings by integrating with sensors for temperature, humidity, and air quality.
• Mining and Materials Handling: Safeguards heavy machinery by monitoring vibration, load, and motor temperature in crushers and conveyors.
• Food and Beverage: Ensures compliance with hygiene standards by accurately measuring process variables in pasteurization and packaging lines.

Compatibility

• System Integration: Seamlessly interfaces with ABB’s Symphony Plus and AC800M control systems, as well as third-party PLCs and HMIs via industry-standard protocols.
• Expandability: Supports multi-module setups for high-channel-count applications, leveraging standardized communication buses for unified control.

Certifications and Compliance

• Safety Standards: CE-marked for compliance with EU directives on low voltage (LVD) and electromagnetic compatibility (EMC).
• Environmental Compliance: RoHS-compliant materials ensure adherence to hazardous substance restrictions.
• Industry Certifications: UL-listed for North American markets, meeting rigorous safety and performance criteria.

Additional Attributes

• Ease of Installation: Plug-and-play design with quick-connect terminals for fast commissioning.
• Longevity: Rugged construction with corrosion-resistant components for reliable performance in harsh conditions.
• Lifecycle Support: Backed by ABB’s global technical support and documentation, including detailed user manuals and software tools.
