1、 Technical specifications
Basic parameters
Product Code: 3BSE008105R1
Brand: ABB
Model: SC560
Product type: Communication Module/Safety Relay (safety relay, may vary depending on different descriptions)
Customs code: 853890 (suitable for use alone or primarily with equipment of heading 85.35, 85.36, or 85.37)
Physical dimensions:
Net depth/length: 486 millimeters
Net height: 27 millimeters
Net width: 288 millimeters
Net weight: 0.76 kg (communication module specification)
Size (safety relay): 66 x 30 x 11.5 mm (length x width x height)
Weight (safety relay): 120g
Power and Signal
Power supply voltage (safety relay): 24V DC
Signal input (safety relay): safety switch signal
Signal output (safety relay): safety relay contact output
2、 Functional Features
Programmable controller host: Built in with CPU, power supply, input/output, and program memory, it can be used as the host of a programmable controller.
Scalability:
Can connect various expansion devices, including expansion units, expansion modules, special units, etc.
The maximum number of expansion points for input and output is 256 (up to 8 for special expansion), and the maximum number of expansion points for CC Link remote I/O can reach 384.
Built in power supply: Some modules (such as expansion power units) provide AC power type built-in power supply to power other modules.
High speed input/output: A special adapter that supports high-speed input and output, improving data processing speed.
Self diagnostic function (safety relay): With self diagnostic function, it can detect its own faults and improve system reliability.
Compliant with standard (safety relay): Compliant with SIL 3/IEC 61508 standard, ensuring high safety level.
Fast response time (safety relay): Response time ≤ 20ms to ensure timely safety control.
3、 Application scenarios
ABB SC560 3BSE008105R1 is widely used in various industrial fields due to its powerful functionality and flexibility, including but not limited to:
Mechanical manufacturing: used to control the start, stop, and operation status of mechanical equipment.
Food processing: Check the status of safety switches in the production line to ensure production safety.
Packaging Machinery: Control various operations during the packaging process to improve production efficiency and safety.
Printing machinery: Ensure precise control and safe operation during the printing process.
Woodworking Machinery: Control the cutting, polishing, and other processes of woodworking machinery to ensure worker safety.
Metal processing: providing precise control and safety protection during the metal processing process.
Safety protection and emergency stop system: As a safety relay, it is used to detect the status of safety switches and control the start and stop of dangerous machines, ensuring the safety of the production site.
