1、 Technical specifications
Power requirements: Supports redundant wide voltage input, including AC power supply of 100-240V AC (50-60Hz 1.2A) and DC power supply of 48V DC. This design improves the reliability and stability of the equipment, ensuring normal operation in different power environments.
Interface type:
RJ45 electrical port: Supports 10/100/1000Base-T rate adaptation, full/half duplex mode, and supports automatic port flipping.
SFP interface: Supports 1000Base or SFP Copper 1000Base-T (supports twisted pair transmission).
Optical port: Supports 1000Base gigabit full duplex, default SC interface, optional FC and ST interfaces, with a transmission distance of up to 120 kilometers.
Console port: RS-232 (RJ45 connector) debugging serial port, used for device configuration and management.
Forwarding performance:
10 Mbps forwarding speed: 14881pps
100Mbps forwarding speed: 148810pps
Gigabit forwarding speed: 1488096pps
System switching bandwidth: 56Gbps
Cache size: 1.5Mbits
MAC address table: 16K
Physical characteristics:
Size (WHD): 482.6mm, 44mm, 275mm
Net weight: 3.15kg
Shell: IP40 level protection, metal shell
Installation method: 1U standard rack
2、 Functional Features
High voltage variable frequency regulation: used to control high-voltage power sources or motors, achieving precise speed and torque control by adjusting the output frequency and voltage.
Modular design: As a pluggable module component, it facilitates installation, replacement, and maintenance.
High performance processor: Built in high-performance processor that can achieve fast data processing and control response.
Multiple communication interfaces: In addition to the Ethernet interfaces mentioned above, it may also support communication protocols such as Modbus and Profibus, facilitating data exchange and communication with other devices or systems.
Protection function: It has overcurrent, overvoltage, overload and other protection functions to protect circuits and equipment from damage.
Stability and reliability: The design is stable and reliable, suitable for long-term industrial applications, and has good anti-interference ability.
Programmable: Supports parameter configuration and programming to meet the needs of different application scenarios.
3、 Application scenarios
The ABB SC510 3BSE003832R1 high-voltage variable frequency regulation board is widely used in the following scenarios due to its powerful functions and wide application areas:
Industrial automation: used to control and regulate high-voltage variable frequency equipment in industrial equipment, such as motors, pumps, etc.
Power system: In the power system, it is used to control the operation of power equipment and regulate power transmission.
Manufacturing: Used in production lines to control the speed and frequency of machine operation, improve production efficiency and product quality.
Building automation: In building management systems, it is used to control the operation of lighting, HVAC, safety systems, and other equipment.
Transportation: may be applied in fields such as traffic signal control, rail transit systems, and vehicle management.
Data Center: In a data center, it is used to connect servers, network equipment, and power systems to ensure the stable operation of the data center.
