Technical Specifications

• Power Supply: Typically operates on a range of DC or AC voltages. Commonly supports 24V DC, 48V DC, or 110V/220V AC, depending on the specific model.
• Communication Protocols: Includes support for communication protocols such as MODBUS, PROFIBUS, and Ethernet for integration into broader control systems.
• Inputs/Outputs:
  • Digital Inputs: Several digital inputs for signal acquisition and monitoring.
  • Digital Outputs: Multiple digital outputs for control functions and signaling.
  • Analog Inputs: Used for measuring variables such as voltage, current, and power.
• Operating Temperature: Designed to operate within a temperature range of -20°C to +60°C (-4°F to +140°F).
• Mounting: Typically designed for DIN rail or panel mounting.

Features

• Advanced Protection and Control Functions: Offers protection functions such as overcurrent, undervoltage, and earth fault, along with control capabilities.
• Real-time Monitoring: Provides real-time data acquisition and system monitoring.
• Configurable Settings: Highly configurable with flexible settings to suit various application requirements.
• Remote Access and Communication: Supports remote monitoring and control via integrated communication interfaces.

Applications

• Industrial Control: Used in industrial settings for controlling and protecting electrical systems.
• Power Distribution: Applied in power distribution networks to ensure reliable operation and protection.
• Energy Management: Utilized in energy management systems to optimize performance and efficiency.
• Substation Automation: Integral in substations for protective and control functions.
