Technical Specifications

• Power Supply: Typically operates on a range of DC voltages. For specific configurations, it often supports 24V DC or 48V DC.
• Communication Protocols: Includes support for industry-standard communication protocols such as Ethernet, MODBUS, and IEC 61850, facilitating integration into modern digital substations.
• Inputs/Outputs:
  • Digital Inputs: Multiple digital inputs for receiving status signals from various components.
  • Digital Outputs: Several digital outputs for control functions and signaling.
  • Analog Inputs: For monitoring process variables such as current and voltage.
• Operating Temperature: Designed to function effectively within a temperature range of -20°C to +60°C (-4°F to +140°F).
• Mounting: Typically designed for panel mounting or rack installation.

Features

• Advanced Protection Functions: Provides a wide range of protection functions including overcurrent, earth fault, and undervoltage protection.
• Flexible Configuration: Highly configurable settings to accommodate various application requirements, with an intuitive user interface for easy setup and operation.
• Real-time Monitoring and Diagnostics: Enables real-time monitoring of electrical parameters and diagnostics for system health and fault analysis.
• Remote Communication: Facilitates remote monitoring and control through integrated communication interfaces, enhancing operational flexibility and system integration.

Applications

• Medium-Voltage Switchgear Protection: Specifically designed for protecting and managing medium-voltage switchgear in electrical distribution networks.
• Industrial Applications: Used in industrial environments where reliable protection and control of electrical equipment are crucial.
• Power Distribution: Implemented in power distribution systems to ensure system reliability and operational safety.
• Substation Automation: Integral to modern substations, providing protection and control functions as part of an automated grid.
