2. Communication Protocol
Supports the IEC61850 communication standard, including IEC 61850-9-2 LE.
Supports Parallel Redundancy Protocol (PRP) and High Availability Seamless Redundancy Protocol (HSR).
Also supports DNP3, IEC 60870-5-103, and Modbus ® Protocol, as well as the Profibus DPV1 protocol supported through the SPA-ZC 302 protocol adapter.
3. Power Supply and Environment
The input voltage range is usually 100-240V AC, suitable for power frequencies of 50/60Hz.
The working temperature range is wide, and it can generally work normally in an environment of -20 ° C to+60 ° C.
2、 Functional Features
1. High precision measurement and calculation
Having high-precision measurement and calculation capabilities, it can monitor power parameters such as current and voltage in real time, ensuring the stable operation of the power system.
2. Multiple protection functions
Providing multiple protection functions such as short circuit, overload, grounding, undervoltage, overvoltage, etc., can effectively protect low-voltage electrical systems and their equipment from damage.
3. High reliability and stability
Adopting advanced digital technology and reliable mechanical structures to ensure long-term stable operation of equipment and reduce failure rates.
4. Flexible configuration and expansion
Provide multiple configuration options to meet different application needs of users. At the same time, the plug-in design supports quick installation and testing, making it easy to maintain and upgrade.
5. Data storage and transmission
Equipped with compact flash memory and internal storage, it can record a large amount of time-series event data, including alarms, relay actions, power outage times, etc. Data can be locked/sealed through storage cards to enhance data security.
Supports CSV format data transfer and can be opened directly in ASCII or spreadsheets without the need for additional software. If higher security is required, the free ReadWin 2000 software can be used for protected data transfer.
6. Friendly user interface
Equipped with a large digital front-end LCD color display, it can read data in both digital and bar chart modes, increasing its applicability. The monitor also has a time-series event list with time and date stamps, making it convenient for users to view historical data.
3、 Application scenarios
ABB REF615C-D HCFCACABANB2BAN1XD is widely used in power systems that require high reliability and stability, including but not limited to the following areas:
Industrial power distribution system: used for protecting, controlling, measuring, and monitoring public and industrial power distribution systems to ensure the safe operation of the power grid.
Low voltage electrical system: protects low-voltage switchgear, motors, generators, transformers and other equipment to prevent equipment damage caused by faults such as short circuits and overloads.
Industrial automation: As an important component of industrial automation control systems, it achieves precise control and monitoring of equipment such as motors, pumps, valves, etc.
Specific industry applications: such as waste management monitoring (such as bioreactors), industrial or pharmaceutical reverse osmosis water systems, tank level monitoring, filtration processes in breweries, fermentation processes, and filling/cleaning machine monitoring.
