ABB RED670 Protective Relay Module for Industrial Automation Applications
The ABB RED670 Protection Relay is designed for high-precision industrial overcurrent protection, ensuring reliable performance in demanding environments. It offers advanced fault detection and protection functions, making it ideal for power systems in various industrial applications.
Detailed content
Product Type:Protective Relay Module
Model:RED670
Brand:ABB
Protection Class:Overcurrent, Earth Fault, Busbar Protection
Rated Voltage:Up to 380 V AC
Rated Current:Up to 630 A
Frequency Range:47-63 Hz
Communication Interface:Modbus RTU, Ethernet/IP
Weight:2.5 kg
Dimensions (D x H x W):20 x 10 x 15 cm
The ABB RED670 Protective Relay Module is engineered to deliver superior protection and control capabilities, ensuring safe and reliable operation in power systems. With its advanced protection functions, including overcurrent, earth fault, interphase fault, and differential protection, it safeguards critical electrical equipment against potential faults and damage.
This module is compatible with a variety of communication interfaces such as Modbus, Ethernet, and IEC 61850, making it highly versatile for integration into existing power system infrastructures. Its compact design, measuring 150mm in height, 100mm in width, and 75mm in depth, allows for easy installation and space-efficient deployment.
Designed to withstand harsh environmental conditions, the ABB RED670 operates within an extended temperature range of -40°C to +85°C and meets the IP65 environmental protection rating, ensuring robust performance even in challenging environments. The module weighs 2.5 kg, making it lightweight yet durable.
Installation and maintenance are straightforward, thanks to its user-friendly interface and comprehensive documentation. Whether you’re working in a substation or a distribution network, the ABB RED670 is a reliable choice for ensuring the integrity and efficiency of your power system.
Upgrade your power system protection and control capabilities with the ABB RED670 Protective Relay Module. Experience unparalleled reliability and performance in your industrial applications.
