• Communication: Integrates with Modbus RTU or Profibus DP for remote monitoring and diagnostics .
• Environmental Ratings:
  • Operational temperature: -25°C to +60°C (extended industrial range).
  • IP54 ingress protection for dust and water spray resistance .

Functional Features

1. Modular Design:
   • Supports scalable configuration with plug-and-play circuit breaker modules.
   • Easy integration into ABB’s Industrial Power Distribution (IPD) systems.
2. Intelligent Monitoring:
   • Embedded metering for real-time voltage, current, and energy consumption data.
   • Fault logging and event history for predictive maintenance.
3. Safety Compliance:
   • Compliant with IEC 61439-1 (low-voltage switchgear) and IEC 60947-2 (circuit breakers) .
   • Arc flash mitigation through selective coordination.

Application Scenarios

1. Industrial Power Distribution:
   • Protects critical loads in manufacturing plants, mining, and water treatment facilities.
2. Motor Control Centers (MCCs):
   • Ensures safe operation of large motors (e.g., pumps, compressors) by isolating faults.
3. Renewable Energy Integration:
   • Safeguards power distribution in solar farms and wind turbine substations.
4. Data Centers:
   • Provides reliable power protection for IT infrastructure and UPS systems .

ABB 3BHE039724R1060

Technical Specifications

• Type: High-Voltage Power Semiconductor Module (IGCT-Based)
• Voltage Rating: Supports 3.3–4.5 kV DC (consistent with ABB’s IGCT series for HVDC applications) .
• Current Capacity: Handles 1,500–3,000 A continuous current, suitable for high-power drives.
• Switching Frequency: Optimized for medium-frequency operation (up to 10 kHz), balancing efficiency and power density.
• Efficiency: Achieves ≥98% energy conversion efficiency with low conduction and switching losses.
• Thermal Management: Direct water-cooling (baseplate temperature ≤85°C) for high-load reliability .
• Dimensions: Compact design (typically 300 x 200 x 50 mm) for modular integration.

Functional Features

1. Integrated Gate-Commutated Thyristor (IGCT) Technology:
   • Enables fast turn-on/off (≤1 μs) with low switching losses, critical for dynamic power control.
2. Dual-Channel Configuration:
   • Supports bipolar operation (positive/negative polarity) for symmetrical power conversion in HVDC systems.
3. Built-in Protection:
   • Overcurrent (OCP) and overtemperature (OTP) detection with fault signal output.
   • Short-circuit withstand capability up to 20 kA .
4. Sensor Integration:
   • Embedded current and temperature sensors for real-time monitoring.

Application Scenarios

1. High-Voltage Direct Current (HVDC) Systems:
   • Enables efficient long-distance power transmission and grid interconnections.
2. Industrial Motor Drives:
   • Powers large synchronous motors in mining, water treatment, and cement production.
3. Renewable Energy Inverters:
   • Converts DC power from solar/wind farms to grid-compatible AC, ensuring stability.
4. Power Quality Compensation:
   • Used in STATCOM (Static Synchronous Compensator) systems to improve power factor.
5. Railway Traction Systems:
   • Supports regenerative braking and traction control in electric locomotives .

Integration and Compatibility

• System Integration: Both devices interface seamlessly with ABB’s System 800xA for centralized control.
• Hardware Compatibility:
  • PPD513A10-111111 works with ABB’s Emax 2 circuit breakers and UNIFLEX power modules.
  • 3BHE039724R1060 integrates with ABB’s HVDC Light and ACS800 drive platforms.
• Software Tools: Configurable via ABB Ability™ Digital Powertrain for performance optimization.

Compliance and Certifications

• Standards: Both products meet IEC 61800-5-1 (adjustable-speed drives) and IEC 60747-16 (semiconductor devices).
• Safety: Compliant with UL 1557 (power semiconductors) and CE marking for EU directives.
• Environmental: Adhere to RoHS and REACH standards for material compliance.

Design Philosophy
