1、 Technical specifications
display:
Type: 8-inch TFT color touch screen
Resolution: 1600 x 1200 pixels, providing high-definition image display.
Display function:
Visualization function: Supports up to 50 four line audio with a maximum of 32 characters per line, with built-in LCD or remote logo display.
Display mode: Supports multiple display modes and effects, such as Ticker text, bar charts, or input/output status switching.
Input:
6 standard touch input buttons
4 additional function input buttons for direct input into program code
Power Supply:
Supports multiple power options: 12 V DC, 24 V AC/DC
Allowable range: 10.2 to 28.8 V DC or 20.4 to 26.4 V AC (47 to 63 Hz)
Other specifications:
Contrast and backlight control
Power consumption under supply voltage: typical value of 65 mA at 24 V DC (typical value of 40 mA at 12 V DC, typical value of 90 mA at 24 V AC)
Installation hole size (width x height x depth): 119.5 x 78.5 x 1.5-4.0 mm (overall size 128.2 x 86 x 38.7 mm)
Compliant with IP65 protection level (when installed correctly on the distribution panel)
2、 Functional Features
High definition display: An 8-inch TFT color touch screen with a resolution of 1600 x 1200 pixels ensures clear and bright images, enhancing the user experience.
Touchscreen interaction: Interacting through the touch screen, such as selection, input, operation, etc., improves operational efficiency and convenience.
Multiple Input/Output: Supports multiple input/output methods, enables connection with external devices, and enhances the flexibility and scalability of the system.
Multi language support: Supports multiple languages to meet the language needs of different users and facilitate applications worldwide.
High reliability and stability: Designed for harsh industrial environments, it has high reliability and stability to ensure long-term stable operation of the system.
Customizability: Customize according to user needs, such as display content, interface design, communication protocols, etc., to meet the requirements of special application scenarios.
3、 Application scenarios
The ABB PP836A 3BSE042237R2 touch screen module is widely used in the field of industrial automation, including but not limited to the following scenarios:
Production line control: In manufacturing, it is used to monitor and control various equipment and machines on the production line to ensure the smooth progress of the production process.
Machine operation interface: As the operation interface of the machine, it provides an intuitive operation interface and rich information display, making it convenient for operators to operate and maintain the equipment.
Automation control system: As an important component of human-machine interaction in automation control systems, it realizes the interaction between PLC and human-machine, and improves the overall performance and reliability of the system.
Process monitoring: used in industries such as chemical, petroleum, and food to monitor and control various parameters in the production process, ensuring product quality and production safety.
