technical specifications
Processor: A high-performance processor that can quickly execute control logic and process data.
Communication interface: Supports multiple communication interfaces, including Ethernet, serial port, CAN bus, etc., supports Profibus DP bus standard, with a wide range of communication rates from 9.6kBit/s to 12MBit/s.
Power supply: DC9-36V wide redundant dual power supply, with DC1500V power isolation and reverse protection function, power consumption less than 4W.
Protection level: IP30, reinforced with wavy aluminum casing, standard industrial 35mm rail installation method.
Lightning protection, overcurrent, and surge protection: Provides 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions.
Functional Features
High performance and reliability: ABB PM803F adopts advanced technology and design, which has high performance and reliability, and can operate stably for a long time in harsh industrial environments.
Multiple communication interfaces: Supports multiple communication protocols and interfaces, facilitating data exchange and integration with other devices and systems.
Programmable: Supports multiple programming languages, such as IEC 61131-3 standard. Users can use different programming languages (such as ladder diagrams, structured text, etc.) to write control logic and achieve customized control requirements.
Flexible configuration: It has flexible configuration options that can be customized according to specific application requirements, including CPU speed, memory capacity, etc.
Remote monitoring and management: Supports remote monitoring and management functions, allowing for remote access, diagnosis, and maintenance of equipment through the network.
Rich input/output interfaces: Provides multiple digital and analog input/output interfaces for connecting sensors, actuators, and other external devices to achieve data acquisition and control.
Application scenarios
ABB PM803F is commonly used in various industrial automation and control applications, including but not limited to the following areas:
Manufacturing industry: used for automated production lines, robot control, packaging machinery, etc.
Process control: used in industries such as chemical, pharmaceutical, and food processing to control process flow, monitor production parameters, etc.
Power distribution: In the power system, it is used to control power distribution, monitor power quality, etc.
Building automation: used in intelligent buildings to control lighting, HVAC, security and other systems.
