ABB IRB52 3HNA006493-001 DSQC1003 & 3HAC046408-001 DSQC609 & 3HAC14178-1, Integrated Manufacturing Solutions
The ABB IRB 52 series with DSQC1003 and DSQC609 modules offer unparalleled precision, efficiency, and adaptability in industrial automation. Tailored for high-demand applications, these solutions streamline manufacturing processes and enhance productivity.
Detailed content
Model:IRB 52 3HNA006493-001
DSQC1003 Function:EtherCAT-based I/O control, supports up to 32 digital inputs and outputs
DSQC609 Function:Standard I/O module, supports up to 16 digital inputs and 16 digital outputs
Max Load Capacity:6kg
Reach Radius:1130mm
Repeatability:+/- 0.03mm
Operating Temperature:-10°C to +45°C
Safety Rating:Class 1, Division 2, Group E,F,G for hazardous locations
Electrical Input Voltage:100-240V AC, 50/60Hz
Communication Interface:EtherCAT, Modbus TCP/IP
The ABB IRB52 series robot modules are designed to integrate directly with our flagship IRB 52 robotic arms, offering unparalleled compatibility and performance enhancements.
The DSQC1003 module supports up to 32 digital I/O signals, enabling precise control over robotic functions without the need for complex wiring. This significantly reduces setup time and enhances operational efficiency.
Conversely, the DSQC609 module extends the capabilities by providing an additional 16 digital I/O signals, allowing for even more extensive customization and integration with external devices.
Both modules are equipped with robust electrical specifications, ensuring reliable operation under a wide range of environmental conditions. Their 12V DC power supply and 1A current consumption make them suitable for a variety of industrial settings.
Their temperature resistance (-20°C to +55°C) ensures durability and reliability in diverse manufacturing environments, from cold storage facilities to hot production lines.
