1. Technical Specifications

• Power Supply: Operates on 24V DC with a tolerance of ±20%.
• Power Consumption: 20W.
• Operating Temperature: -20°C to 70°C.
• Storage Temperature: -40°C to 85°C.
• Dimensions: 230 x 160 x 50 mm.
• Weight: 1.5 kg.
• Processor: High-speed processor, ensuring efficient data processing.
• Memory: 8 GB DDR4.
• Storage: 256 GB SSD.
• Communication Interfaces: RS-232 (standard), with optional RS-485 support.
• I/O Points: 24 points, which can be expanded based on system requirements.
• Input Current: Maximum 5 mA for digital inputs and 0.5 A for analog inputs.
• Output Frequency: 100 Hz.
• Processing Speed: 550 μs.
• Program and Data Capacity: 300 and 200, respectively.

2. Functional Features

• RoHS Compliance: The board adheres to the Restriction of Hazardous Substances (RoHS) directive, ensuring that it does not contain restricted substances such as lead, mercury, cadmium, and others. This makes it environmentally friendly and suitable for applications where environmental regulations are critical.
• High Reliability: Designed for stable operation in demanding industrial environments, with robust construction and advanced error-handling mechanisms.
• Modular Design: Supports flexible installation, upgrades, and maintenance, allowing for easy integration into existing systems.
• High-Speed Processing: Capable of handling complex control logic and real-time data processing efficiently.
• Scalability: The I/O points and communication interfaces can be customized to meet specific application needs.
• Safety Features: High-level safety standards, including protection against electrical noise and transient overvoltages.

3. Application Scenarios

The ABB COAT-ROHS is well-suited for a variety of industrial automation applications, particularly those requiring strict environmental compliance and high performance. Some key application scenarios include:

• Manufacturing and Industrial Automation: Used in machinery control, robotics, and process automation where precise and reliable operation is essential.
• Environmental Monitoring Systems: Its RoHS compliance makes it ideal for applications in industries such as environmental monitoring, where hazardous materials must be avoided.
• Energy and Power Management: Suitable for power plants and renewable energy systems, where efficient control and adherence to environmental standards are crucial.
• Food and Beverage Processing: The board’s reliability and compliance with RoHS make it suitable for hygienic and sensitive environments.
• Building Automation: Applied in HVAC systems and smart building solutions, where long-term stability and environmental safety are important.
