Technical Specifications
| Specification | Description |
|---|---|
| Model | CI801 |
| Manufacturer | ABB |
| Power Supply | DC24V, with internal DC/DC isolation conversion |
| Power Consumption | <10W |
| Input Specifications | 8 points, 7mA per point |
| Output Specifications | 6 points, transistor output type: 2A/point |
| Accuracy | 12-bit |
| Program Capacity | 2K steps |
| Auxiliary Relays | 512 points (M class), 128 points (S class) |
| Timers & Counters | 64 each |
| Data Memory | 256 general registers, 256 special registers |
| High-Speed Counters | 20 x 32-bit, support increase/decrease counting, 1-Phase 100kHz (2 points), 10kHz (4 points) |
| Communication Interfaces | USB virtual serial port, RS422/RS232/RS485, Ethernet (network), parallel link, computer link |
| Operating Frequency | 50Hz |
| Power Type Range | DC22V to DC28V |
| Clock Function | Built-in real-time clock with 100-year calendar saving, week automatic calculation |
Functional Features
- High-Speed Transmission: CI801 employs advanced transmission technology to achieve high-speed and stable data transmission, meeting the demands of fast-paced industrial applications.
- Multi-Protocol Support: It supports various communication protocols, including TCP/IP, UDP, Modbus, etc., providing flexibility for users to configure according to their specific needs.
- Strong Compatibility: CI801 is compatible with multiple hardware devices, such as sensors and PLCs, facilitating seamless integration and system expansion.
- Reliable and Stable: With its robust design, CI801 ensures reliable and stable operation even in harsh industrial environments, safeguarding the continuous operation of systems.
- Data Processing Capabilities: It includes features like data parsing, storage, analysis, and control, enabling complex data manipulation and decision-making.
- High-Speed Processing: Supports input and output refresh, input filter adjustment, input interrupt function, and pulse capture function for precise and responsive control.
Application Scenarios
- Industrial Automation: CI801 is widely used in industrial automation systems for communication between PLCs, DCS systems, and other control devices, enabling efficient data transmission and control.
- Process Control: In process industries, it helps in monitoring and controlling various process variables, ensuring process stability and product quality.
- Machine Control: Integrated into machines for real-time monitoring and control, CI801 facilitates automated operations and enhances machine performance.
- Data Acquisition and Monitoring: Utilized in systems that require continuous data acquisition and monitoring, such as energy management and remote monitoring applications.
