Type:IGBT Module

Model Number:5SNA0600G650122

Rated Current:600A

Rated Voltage:650V

Operating Temperature Range:-40°C to +175°C

Insulation Resistance:≥10^10 Ohms @ 500V DC

Max Gate Drive Voltage:±25V

Max Gate Drive Current:50mA

Switching Frequency:Up to 5 kHz

Cooling Method:Air Cooling

Dimension (WxHxD):150mm x 70mm x 50mm

Weight:0.3kg

    The ABB 5SNA0600G650122 IGBT Module stands out in its class for its robust design, ensuring seamless integration into complex industrial systems. Its advanced semiconductor technology enables efficient handling of high power loads with minimal losses, making it an ideal choice for applications requiring precise and reliable power management.

    Crafted with premium materials, this IGBT module boasts exceptional thermal and electrical performance, capable of operating under extreme conditions without compromising efficiency. Its wide temperature range (-40°C to +125°C) ensures reliability in diverse industrial environments.

    The module features a compact yet robust package design that facilitates easy installation and maintenance, minimizing downtime for your production processes. Its active air cooling system ensures optimal heat dissipation, even during peak operation periods, thus prolonging the life cycle of the module.

    With a digital signal input interface, the ABB 5SNA0600G650122 IGBT Module offers seamless control integration, enabling precise and responsive control over power distribution. This feature is particularly advantageous in applications where fine-tuning of power levels is critical for system performance.

    Backed by ABB’s commitment to innovation and quality, the 5SNA0600G650122 IGBT Module comes with comprehensive technical support and a warranty, ensuring peace of mind for users. It is designed to withstand rigorous testing and operational demands, providing a reliable solution for power conversion in industries ranging from manufacturing to renewable energy.
