Model:3HAA3563-ALG/2

Manufacturer:ABB

Module Type:Automation

Category:DCS (Distributed Control System)

Dimensions:LxWxH (mm)

:150x100x30

Weight:0.2 kg

Operating Temperature Range:-20°C to +60°C

Input Voltage:12 to 48V DC

Output Voltage:5 to 30V DC

Operating Current:Max 1A

Communication Protocol:Modbus RTU/TCP

Connection Ports:1 x RS-485, 1 x Ethernet

Relay Outputs:1 x SPDT relay

Status Indicators:2 x LED indicators

    The ABB 3HAA3563-ALG/2 Circuit Board Automation DCS Module is designed to enhance operational efficiency in demanding industrial environments. It seamlessly integrates with various control systems, offering unparalleled accuracy and reliability.

    With its advanced microcontroller technology, this module ensures real-time monitoring and control, optimizing processes across different industries. Its wide operating voltage range makes it suitable for applications with varying power supplies.

    Featuring Modbus and Ethernet/IP communication protocols, the module supports seamless integration with existing systems, facilitating easy data exchange and remote access. The ample memory size ensures smooth operation even under high data throughput scenarios.

    Operated within a temperature range of -25°C to +60°C, this module maintains optimal performance under harsh conditions, making it ideal for outdoor or process control environments.

    Manufactured with high-quality materials, the 3HAA3563-ALG/2 Circuit Board is built to withstand rigorous industrial use, ensuring long-lasting service life and minimal maintenance requirements.
