ABB 3BHE039724R0C3D

Digital guide

Voltage Input: Supports a 24V DC power supply, ensuring compatibility with standard industrial control systems.
Current Handling: Manages medium to high-power loads (specific ratings depend on application configuration).
Cycle Time: Achieves 100 μs to milliseconds processing speeds for fast control loops, critical for real-time applications like LED lighting and motor drives.
Communication Protocols: Integrates with Modbus RTU and PowerLink for seamless data exchange with PLCs and other automation devices.

Communication Protocols: Integrates with Modbus RTU and PowerLink for seamless data exchange with PLCs and other automation devices.
Environmental Ratings: Operates in temperatures ranging from -20°C to +60°C and withstands humidity up to 95% RH, ensuring reliability in harsh industrial settings.
Dimensions: Compact design optimized for DIN-rail mounting, with dimensions of 130 x 40 x 120 mm for space-efficient installation.
Processing Speed: Features a 400 MHz processor for high-speed data handling and algorithm execution.
Output Frequency: Supports 350 kHz switching frequency for efficient power conversion in applications like LED drivers.

High-Speed Control: Leverages FPGA technology to execute complex algorithms with sub-microsecond precision, ideal for dynamic processes like LED brightness and color temperature adjustment.
Comprehensive Protection: Equipped with overcurrent, short-circuit, and over-temperature safeguards, preventing equipment damage during fault conditions.
Modular Architecture: Supports plug-in I/O modules for scalable configurations, allowing customization for specific applications (e.g., additional analog/digital channels).
Programming Flexibility: Compatible with IEC 61131-3 programming languages (e.g., ladder logic, function block diagram) and MATLAB/Simulink for model-based development.
Real-Time Monitoring: Provides voltage, current, and power factor tracking via integrated sensors, enabling proactive maintenance and energy optimization.
IGCT Integration: Incorporates Integrated Gate-Commutated Thyristor (IGCT) technology for high-power applications, offering low conduction losses and high switching reliability.

LED Lighting Systems:
- Used in commercial and industrial lighting to regulate brightness, color temperature, and dimming profiles with high accuracy.
- Supports smart building automation by integrating with occupancy sensors and energy management systems.
Industrial Automation:
- Controls motor drives and conveyor systems in manufacturing plants, ensuring smooth operation and energy efficiency.
- Manages power distribution in substation environments, protecting critical equipment from overloads.
Power Electronics:
- Optimizes synchronous generator excitation in power plants, stabilizing grid connections and reducing harmonic distortion.
- Supports renewable energy systems (e.g., solar inverters) by managing power conversion and grid synchronization.
Process Control:
- Implements PID algorithms in water treatment facilities to regulate pump speeds and chemical dosing.
- Monitors HVAC systems in smart buildings, balancing energy consumption and environmental comfort.

Standards: Meets IEC 61000-6-2 (EMC immunity) and IEC 60947-2 (low-voltage switchgear) requirements for industrial use.
Safety: Compliant with UL 508 (industrial control equipment) and CE marking for European Union directives.

System Integration: Seamlessly interfaces with ABB Ability™ System 800xA, enabling centralized monitoring and data analytics across plant-wide operations.
Hardware Compatibility: Works with AC800PEC I/O modules and ACS880 drives for unified control and diagnostics.
Software Tools: Configurable via ABB Compact Control Builder, a user-friendly platform for programming, simulation, and troubleshooting.
