Model Number:3AUA0000109332

IGBT Type:FS450R12KE3

Module Type:AGDR-81C

Maximum Continuous Current:450 A

Maximum Reverse Voltage:1200 V

Switching Frequency:Up to 10 kHz

Cooling Method:Air cooling

Input Output Connections:Optimized for easy connection and configuration

Dimension:365mm x 120mm x 25mm

Weight:Approx. 2.5 kg

Certifications:UL, CE, RoHS compliant

    Engineered for optimal performance in high-demand industrial environments, the ABB 3AUA0000109332 – FS450R12KE3/AGDR-81C IGBT Module SP Kit leverages cutting-edge technology to provide unparalleled precision in current control, essential for achieving peak operational efficiency.

    Featuring a robust water-cooling system, this module ensures reliable operation over a wide temperature range, from -40°C to +125°C, making it suitable for various industrial applications worldwide.

    With a power rating of 450 Amps at 1200V, it supports demanding electrical loads while maintaining high efficiency and minimizing energy loss.

    The inclusion of advanced AGDR-81C technology enables the module to handle complex switching frequencies up to 12kHz, ensuring smooth and seamless integration into modern control systems.

    Equipped with class 1 insulation, the module boasts enhanced safety and reliability, meeting international standards for electrical safety and performance.

    Ideal for integration into existing or new industrial control systems, the ABB 3AUA0000109332 – FS450R12KE3/AGDR-81C IGBT Module SP Kit offers a comprehensive solution for enhancing system performance and reliability, backed by ABB’s industry-leading support and expertise.
