Operating Voltage:600V

Current Rating:120A

Switching Frequency:50kHz

Thermal Resistance:≤1°C/W

Insulation Resistance:≥10MΩ

Operating Temperature Range:-40°C to +170°C

Package Type:TO-247

Cooling Method:Air Cooled

Certifications:[“IEC 60950″,”UL 60950”]

    The ABB 2MBI600VX-120-50 IGBT Modules are engineered for demanding industrial environments, offering exceptional performance in high-power conversion tasks. They are renowned for their ability to handle large currents and voltages with minimal energy loss, ensuring optimal system efficiency.

    These modules are equipped with advanced insulation technology, providing Class F protection against electrical breakdown, which extends their operational lifespan significantly compared to standard IGBTs.

    With a wide operating temperature range from -40°C to +170°C, they are suitable for a variety of industrial applications across different climates and environments, from harsh industrial settings to extreme temperatures.

    The water-cooling method ensures efficient heat dissipation, allowing the modules to operate continuously without overheating, even under heavy loads. This makes them ideal for applications requiring high power density and continuous operation.

    The inclusion of a terminal block for input/output connections simplifies installation and maintenance, while the Profibus DP interface enables seamless integration with existing industrial automation systems, enhancing system interoperability and ease of control.
