AB 2198-S086-ERS3 Single-Axis Servo Module: Precision Control in Industrial Automation
The AB 2198-S086-ERS3 Single-Axis Servo Module offers unparalleled precision and control for industrial automation applications, enabling seamless integration and high-performance operation across various machinery and systems.
Detailed content
Model Number:2198-S086-ERS3
Module Type:Single-Axis Servo
Control System Compatibility:AB’s Advanced Motion System
Input Voltage:24V DC
Operating Frequency:Up to 1 kHz
Motor Compatibility:Wide range of AB motors
Resolution:Up to 1024 pulses per revolution
Speed Control:Accurate and responsive
Torque Capacity:Dependent on motor selection
Communication Protocol:EtherCAT
Dimensions (WxHxD):96.5mm x 64mm x 144mm
Weight:Approx. 0.4kg
The AB 2198-S086-ERS3 Single-Axis Servo Module is designed to deliver high-performance in industrial automation, boasting a compact yet robust design that ensures reliable operation under extreme conditions.
Featuring advanced EtherCAT communication technology, this module enables fast and efficient data exchange, optimizing system responsiveness and throughput.
With its universal motor compatibility, the AB 2198-S086-ERS3 seamlessly integrates with a wide range of industrial machinery, enhancing versatility and reducing setup time.
Precision is at the core of this module, offering an unparalleled control accuracy of ±0.01°, making it ideal for applications requiring high levels of precision and repeatability.
Equipped with a high load capacity of up to 20kgf, this servo module can handle demanding workloads, ensuring consistent performance across various tasks and operations.
