AB 1794-IA8I Input Module for Industrial Control Systems
The AB 1794-IA8I Input Module is an integral part of Allen-Bradley’s programmable logic controllers, designed to facilitate reliable data acquisition from various sources, ensuring efficient operation in industrial automation environments.
Detailed content
Type:Analog Input Module
Model:AB 1794-IA8I
Voltage Rating:120VAC
Number of Inputs:8
Connection Type:Terminal Block
Operating Temperature Range:-40°C to +70°C
Enclosure Type:IP20 (NEMA 1)
Communication Protocol:DeviceNet, Modbus-RTU
Operating Current:≤20mA per channel
Power Supply Requirement:24VDC
Dimensions (WxHxD):110mm x 110mm x 96mm
The AB 1794-IA8I Input Module is a robust and versatile component specifically engineered for integration into complex industrial automation systems. Its high channel capacity ensures efficient data acquisition and processing.
Each channel is capable of accurately sensing and transmitting 120VAC signals, making it ideal for applications requiring precise electrical input monitoring, such as temperature sensors, motor control circuits, and safety switches.
Equipped with an extensive operating temperature range (-40°C to +85°C), this module can withstand harsh industrial environments, ensuring reliable performance throughout its lifecycle.
Featuring a terminal block connector, it offers flexibility and ease of installation, allowing for quick setup and maintenance without compromising on functionality or safety standards.
The Modbus communication interface facilitates seamless integration with existing control systems, enhancing the overall efficiency and connectivity within the automation network. This compatibility is crucial for modern industrial settings where interoperability is key.
