AB 1786-BNCP – Allen-Bradley ControlNet BNC Coaxial Connector
The AB 1786-BNCP is a high-performance BNC Coaxial Connector designed for seamless integration in industrial automation networks, offering reliable signal transmission and enhanced data transfer rates for ControlNet applications.
Detailed content
Connector Type:BNC
Connection Type:Coaxial
Application Environment:Industrial Automation
Network Compatibility:ControlNet
Material:High-grade Copper
Environmental Rating:IP20
Operating Temperature Range:-40°C to +85°C
Weight:0.05kg
Connector Quantity:Single
Data Rate:Up to 10Mbps
Pin Configuration:7-pin
Certifications:UL, CE, RoHS
The AB 1786-BNCP ControlNet BNC Coaxial Connector is engineered to meet the stringent demands of industrial environments. Its robust design ensures seamless integration into various automation systems, enhancing operational efficiency.
Featuring a BNC connection type, this connector provides a secure and reliable interface for transmitting data at high speeds, crucial for real-time control applications. It is specifically optimized for ControlNet networks, ensuring compatibility and performance.
Built with reinforced plastic, the connector is both durable and lightweight, providing longevity in harsh industrial conditions without compromising on performance. It can withstand temperature fluctuations from -40°C to +70°C, making it suitable for a wide range of industrial applications.
Withstanding electrical ratings up to 1000 Vrms, the AB 1786-BNCP is capable of handling demanding power and signal transmission requirements. Its coaxial structure minimizes signal loss and interference, ensuring clear and consistent data flow.
Installation and maintenance are simplified with its straightforward design, allowing for quick setup and easy troubleshooting. The connector is designed to minimize downtime and enhance overall system reliability, making it an indispensable component in modern industrial automation setups.
