A-B 1746-N2 SLC 500 Digital Input Module, 8 Points, 24VDC

The AB 1746-N2 is an advanced digital input module designed for industrial automation systems. It offers reliable and accurate signal acquisition for monitoring various industrial processes.

WhatApp

WeChat

Detailed content

Brand:AB

Model:1746-N2

Type:Analog Output Module

Channels:4-channel

Operating Voltage:24VDC

Output Range:0 – 21.5 mA

Output Accuracy:±0.5% of reading + 1 μA

Current Rating:Backplane: 120 mA at 5 VDC, 250 mA at 24 VDC (J4 jumper set to rack), 0 mA at 24 VDC (J4 jumper set to EXT)

Isolation:Backplane: 500 VDC

Connection Cables:24 – 14 AWG

Mounting:Chassis-mounted

The Allen-Bradley 1746-N2 digital input module is engineered for reliability and efficiency in industrial environments. Designed for seamless integration with Allen-Bradley SLC 500 controllers, this module offers robust performance with eight digital input points. Each input point supports 24 VDC, sink-type inputs, ensuring reliable signal detection. The module features a fast response time of up to 1 ms, making it ideal for real-time data acquisition. With a wide operating temperature range from -40°C to +85°C, it can withstand harsh industrial conditions. The Allen-Bradley 1746-N2 is certified by UL, CSA, and CE standards, providing assurance of quality and safety. This module is perfect for applications requiring precise and reliable digital input signals.
